Strong Neodymium Ring Magnets N35, N38, N42, N45, N50 & N52. Neodymium Ring Magnets are widely used in such applications as holding, motors, consumer electronics, medical, sensors and speakers. Due to the high magnetic strength of a Rare Earth Magnet, it has replaced other magnetic materials in order to make a design smaller but achieve the same result.
Speaker Ring Magnets N35 OD30xID20x5mm
Speaker Ring Magnets N35 OD30xID20x5
- Min.Order Quantity: 1000 Piece/Pieces
- Solution: Customized you required grade, size, coating, shape, pull force and woking temperature
Magnet Size
Maximum operating temperature
Rare earth magnets include neodymium magnets and Samarium-Cobalt magnets. The Speaker Ring Magnets N35 OD30xID20x5 on the pictures are made from neodymium magnetic material. The dimension is OD30xID20x5mm, axially magnetized.
BUILD YOUR CUSTOM MAGNETS
Request a quote today
Specifications
- Material NdFeB
- Grade N35
- Shape Ring
- Coating Ni-Cu-Ni
- Max temperature 80˚C (176˚F)
- Outer diameter (OD) 30 mm
- Inner diameter (ID) 20 mm
- Thickness (H) 5 mm
- Tolerance +/- 0.1mm
In order to quote you the best price quickly . please provide the following information:
- Product size, grade, coating ect
- Order quantity
- Attached the drawing if customized
